Threaded Unions & Adapters: De Universele Probleemoplossers

In een modern laboratorium komen vloeistofsystemen uit alle werelddelen samen. Dit betekent vaak een uitdagende mix van verschillende schroefdraden en poortontwerpen. Inacom biedt een allesomvattend assortiment threaded unions en adapters om nagenoeg elke Engelse of metrische poort lekvrij met elkaar te verbinden.

Of u nu een overgang zoekt tussen een conische HPLC-poort en een vlakke lagedrukaansluiting, of een industriële NPT-verbinding moet integreren in uw analytische systeem: Inacom heeft de passende koppeling.

Prod. No.	Description**	Includes	Thru-hole	Swept Volume	Pressure Rating
6000-076	PEEK Adapter, 5/16-24 C, M to 10-32 C, F	–	0.066″ (1.70 mm)	49.8 µL	3,000 psi (207 bar)
P-135	PEEK Adapter, 5/16-24 FB, F to 1/4-28 F	–	0.080″ (2.05 mm)	4.1 µL	1,000 psi (69 bar)
P-627	PEEK Adapter, 10-32 C, F to 1/4-28 FB, F	F-300	0.020” (0.50 mm)	0.30 µL	1,000 psi (69 bar)
P-649	PEEK Adapter, 5/16-24 FB, F to 1/4-28 FB, M	–	0.063″ (1.60 mm)	24.5 µL	1,000 psi (69 bar)
P-674	PEEK Adapter, 5/16-24 FB, F to 1/4-28 FB, M	–	0.040″ (1.00 mm)	9.9 µL	1,000 psi (69 bar)
P-681	PEEK Adapter, 5/16-24 FB, F to 1/4-28 FB, M	–	0.125″ (3.20 mm)	96.6 µL	1,000 psi (69 bar)
P-684	PEEK Adapter, 1/2-20 FB, F to 1/4-28 FB, M	–	0.130″ (3.30 mm)	121.7 µL	250 psi (17 bar)
P-718	PEEK Adapter, 5/16-24 FB, M to 1/4-28 FB, F	–	0.040″ (1.00 mm)	10.3 µL	1,000 psi (69 bar)
U-659	PEEK Adapter, 5/16-24 FB, F to 1/2-20 FB, F	U-655, U-650	Tapered***	42.0 µL	250 psi (17 bar)
U-665	PEEK Adapter, 1/2-20 FB, F to 1/4-28 FB, F	U-655, U-650	0.063” (1.60 mm)	6.6 µL	250 psi (17 bar)
P-652	PEEK Adapter, 1/4-28 FB, F to 10-32 C, M	–	0.030” (0.75 mm)	6.7 µL	1,000 psi (69 bar)
P-654	PEEK Adapter, 1/4-28 FB, F to 10-32 C, M, Extra Long	–	0.030” (0.75 mm)	9.5 µL	1,000 psi (69 bar)
P-669-01	PEEK Adapter, 10-32 C, F to 1/4-28 FB, M	–	0.040” (1.00 mm)	6.6 µL	1,000 psi (69 bar)
P-671	PTFE Adapter, 1/4-28 FB, F to 1/4-28 FB, M	–	0.040” (1.00 mm)	8.0 µL	1,000 psi (69 bar)
P-672	PEEK Adapter, 1/4-28 FB, F to 10-32 FB, M	–	0.050” (1.25 mm)	11.4 µL	1,000 psi (69 bar)

Prod. No.

Description**

Includes

Thru-hole

Swept Volume

Pressure Rating

6000-076

PEEK Adapter, 5/16-24 C, M to 10-32 C, F

–

0.066″ (1.70 mm)

49.8 µL

3,000 psi (207 bar)

P-135

PEEK Adapter, 5/16-24 FB, F to 1/4-28 F

–

0.080″ (2.05 mm)

4.1 µL

1,000 psi (69 bar)

P-627

PEEK Adapter, 10-32 C, F to 1/4-28 FB, F

F-300

0.020” (0.50 mm)

0.30 µL

1,000 psi (69 bar)

P-649

PEEK Adapter, 5/16-24 FB, F to 1/4-28 FB, M

–

0.063″ (1.60 mm)

24.5 µL

1,000 psi (69 bar)

P-674

PEEK Adapter, 5/16-24 FB, F to 1/4-28 FB, M

–

0.040″ (1.00 mm)

9.9 µL

1,000 psi (69 bar)

P-681

PEEK Adapter, 5/16-24 FB, F to 1/4-28 FB, M

–

0.125″ (3.20 mm)

96.6 µL

1,000 psi (69 bar)

P-684

PEEK Adapter, 1/2-20 FB, F to 1/4-28 FB, M

–

0.130″ (3.30 mm)

121.7 µL

250 psi (17 bar)

P-718

PEEK Adapter, 5/16-24 FB, M to 1/4-28 FB, F

–

0.040″ (1.00 mm)

10.3 µL

1,000 psi (69 bar)

U-659

PEEK Adapter, 5/16-24 FB, F to 1/2-20 FB, F

U-655, U-650

Tapered***

42.0 µL

250 psi (17 bar)

U-665

PEEK Adapter, 1/2-20 FB, F to 1/4-28 FB, F

U-655, U-650

0.063” (1.60 mm)

6.6 µL

250 psi (17 bar)

P-652

PEEK Adapter, 1/4-28 FB, F to 10-32 C, M

–

0.030” (0.75 mm)

6.7 µL

1,000 psi (69 bar)

P-654

PEEK Adapter, 1/4-28 FB, F to 10-32 C, M, Extra Long

–

0.030” (0.75 mm)

9.5 µL

1,000 psi (69 bar)

P-669-01

PEEK Adapter, 10-32 C, F to 1/4-28 FB, M

–

0.040” (1.00 mm)

6.6 µL

1,000 psi (69 bar)

P-671

PTFE Adapter, 1/4-28 FB, F to 1/4-28 FB, M

–

0.040” (1.00 mm)

8.0 µL

1,000 psi (69 bar)

P-672

PEEK Adapter, 1/4-28 FB, F to 10-32 FB, M

–

0.050” (1.25 mm)

11.4 µL

1,000 psi (69 bar)

Prod. No.*	Description**	Includes	Thru-hole	Swept Volume	Pressure Rating
P-626	PEEK Adapter, 10-32 C, F to M6 FB, F	F-300	0.020” (0.50 mm)	0.3 µL	1,000 psi (69 bar)
P-650	PEEK Adapter, M6 FB, F to 10-32 C, M	–	0.030” (0.75 mm)	6.7 µL	1,000 psi (69 bar)
P-670	PEEK Adapter, M6 FB, F to 1/4-28 FB, M	–	0.030” (0.75 mm)	2.6 µL	1,000 psi (69 bar)
P-673	PEEK Adapter, 5/16-24 FB, F to M6 FB, M	–	0.040″ (1.00 mm)	9.9 µL	1,000 psi (69 bar)
P-694	PEEK Adapter, 1/4-28 FB, F to M6 FB, M	–	0.040″ (1.00 mm)	11.3 µL	1,000 psi (69 bar)
P-920-01	PEEK Adapter, 10-32 C, F to M6 FB, M	–	0.040″ (1.00 mm)	8.0 µL	1,000 psi (69 bar)
**F = Female (internal) threads; M = Male (external) threads; XL = extra long; C = Coned; FB = Flat-Bottom

Prod. No.*

Description**

Includes

Thru-hole

Swept Volume

Pressure Rating

P-626

PEEK Adapter, 10-32 C, F to M6 FB, F

F-300

0.020” (0.50 mm)

0.3 µL

1,000 psi (69 bar)

P-650

PEEK Adapter, M6 FB, F to 10-32 C, M

–

0.030” (0.75 mm)

6.7 µL

1,000 psi (69 bar)

P-670

PEEK Adapter, M6 FB, F to 1/4-28 FB, M

–

0.030” (0.75 mm)

2.6 µL

1,000 psi (69 bar)

P-673

PEEK Adapter, 5/16-24 FB, F to M6 FB, M

–

0.040″ (1.00 mm)

9.9 µL

1,000 psi (69 bar)

P-694

PEEK Adapter, 1/4-28 FB, F to M6 FB, M

–

0.040″ (1.00 mm)

11.3 µL

1,000 psi (69 bar)

P-920-01

PEEK Adapter, 10-32 C, F to M6 FB, M

–

0.040″ (1.00 mm)

8.0 µL

1,000 psi (69 bar)

**F = Female (internal) threads; M = Male (external) threads; XL = extra long; C = Coned; FB = Flat-Bottom

Prod. No.	Description**	Color	Tubing	Includes	Thru-hole	Swept Volume	Pressure Rating
U-510	PEEK 1/8” NPT, M to 1/4-28 FB, F Adapter	Red	1/8″ OD	P-308, P-300	0.062” (1.60 mm)	17.3 µL	500 psi (34 bar)
U-514	PEEK 1/8” NPT, M to 5/16-24 FB, F Adapter	Natural	3/16” OD	P-132, P-133	0.125” (3.2 mm)	70.4 µL	500 psi (34 bar)
U-500	PEEK 1/4” NPT, M to 1/4-28 FB, F Adapter	Red	1/8″ OD	P-308, P-300	0.062” (1.60 mm)	17.3 µL	500 psi (34 bar)
U-504	PEEK 1/4” NPT, M to 5/16-24 FB, F Adapter	Natural	3/16” OD	P-132, P-133	0.125” (3.2 mm)	70.4 µL	500 psi (34 bar)
**F = Female (internal) threads; M = Male (external) threads; XL = extra long; C = Coned; FB = Flat-Bottom

Prod. No.

Description**

Color

Tubing

Includes

Thru-hole

Swept Volume

Pressure Rating

U-510

PEEK 1/8” NPT, M to 1/4-28 FB, F Adapter

Red

1/8″ OD

P-308, P-300

0.062” (1.60 mm)

17.3 µL

500 psi (34 bar)

U-514

PEEK 1/8” NPT, M to 5/16-24 FB, F Adapter

Natural

3/16” OD

P-132, P-133

0.125” (3.2 mm)

70.4 µL

500 psi (34 bar)

U-500

PEEK 1/4” NPT, M to 1/4-28 FB, F Adapter

Red

1/8″ OD

P-308, P-300

0.062” (1.60 mm)

17.3 µL

500 psi (34 bar)

U-504

PEEK 1/4” NPT, M to 5/16-24 FB, F Adapter

Natural

3/16” OD

P-132, P-133

0.125” (3.2 mm)

70.4 µL

500 psi (34 bar)

**F = Female (internal) threads; M = Male (external) threads; XL = extra long; C = Coned; FB = Flat-Bottom

Prod. No.	Description	Color	Threads**	Includes	Thru-hole	Swept Volume	Pressure Rating
P-702	PEEK Union for 1/16” OD Tubing	Natural	1/4-28 FB	P-235 (2), P-200 (2)	0.020” (0.50 mm)	0.41 µL	1,000 psi (69 bar)
P-703	PEEK Union for 1/8” OD Tubing	Natural	1/4-28 FB	P-335 (2), P-300 (2)	0.050” (1.25 mm)	2.57 µL	1,000 psi (69 bar)
P-630	ETFE True ZDV Union for 1/16” OD Tubing	Natural	1/4-28 FB	P-245 (2), P-200N (2)	–	–	1,000 psi (69 bar)
P-631	ETFE True ZDV Union for 1/8” OD Tubing	Natural	1/4-28 FB	P-345 (2), P-300N (2)	–	–	1,000 psi (69 bar)
P-710	ETFE Union for 1/16” OD Tubing	Natural	1/4-28 FB	P-245 (2), P-200 (2)	0.030” (0.75 mm)	0.93 µL	1,000 psi (69 bar)
P-603	Delrin True ZDV Standard Union	Natural	1/4-28 FB	–	–	–	***
P-620	Polypropylene True ZDV Standard Union	Natural	1/4-28 FB	–	–	–	***
P-623	ETFE True ZDV Standard Union	Natural	1/4-28 FB	–	–	–	***
P-602	Delrin Metric Union	Black	M6 FB	–	0.020” (0.50 mm)	0.41 µL	***
P-622	ETFE Metric Union	Black	M6 FB	–	0.020” (0.50 mm)	0.41 µL	***
P-645	PEEK Male Union	Natural	1/4-28 FB	–	0.062” (1.60 mm)	61.3 µL	500 psi (34 bar)
P-845-01	PEEK Union for 1/16” OD Tubing	Red	10-32 FB	–	0.020” (0.50 mm)	0.20 µL	***
**FB = Flat-Bottom
***Pressure rating depends on the fitting used

Prod. No.

Description

Color

Threads**

Includes

Thru-hole

Swept Volume

Pressure Rating

P-702

PEEK Union for 1/16” OD Tubing

Natural

1/4-28 FB

P-235 (2), P-200 (2)

0.020” (0.50 mm)

0.41 µL

1,000 psi (69 bar)

P-703

PEEK Union for 1/8” OD Tubing

Natural

1/4-28 FB

P-335 (2), P-300 (2)

0.050” (1.25 mm)

2.57 µL

1,000 psi (69 bar)

P-630

ETFE True ZDV Union for 1/16” OD Tubing

Natural

1/4-28 FB

P-245 (2), P-200N (2)

–

1,000 psi (69 bar)

P-631

ETFE True ZDV Union for 1/8” OD Tubing

Natural

1/4-28 FB

P-345 (2), P-300N (2)

–

1,000 psi (69 bar)

P-710

ETFE Union for 1/16” OD Tubing

Natural

1/4-28 FB

P-245 (2), P-200 (2)

0.030” (0.75 mm)

0.93 µL

1,000 psi (69 bar)

P-603

Delrin True ZDV Standard Union

Natural

1/4-28 FB

–

***

P-620

Polypropylene True ZDV Standard Union

Natural

1/4-28 FB

–

***

P-623

ETFE True ZDV Standard Union

Natural

1/4-28 FB

–

***

P-602

Delrin Metric Union

Black

M6 FB

–

0.020” (0.50 mm)

0.41 µL

***

P-622

ETFE Metric Union

Black

M6 FB

–

0.020” (0.50 mm)

0.41 µL

***

P-645

PEEK Male Union

Natural

1/4-28 FB

–

0.062” (1.60 mm)

61.3 µL

500 psi (34 bar)

P-845-01

PEEK Union for 1/16” OD Tubing

Red

10-32 FB

–

0.020” (0.50 mm)

0.20 µL

***

**FB = Flat-Bottom

***Pressure rating depends on the fitting used

Prod. No.	Description	Threads	Color	Includes	Thru-hole	Swept Volume
P-440	PEEK Bulkhead Union	10-32 Coned	Natural	SST Nut/Washer	0.020” (0.50 mm)	1.9 µL
P-441	PEEK Bulkhead Union	1/4-28 Flat-Bottom	Red	SST Nut/Washer	0.040” (1.00 mm)	2.9 µL
P-441N	PEEK Bulkhead Union	1/4-28 Flat-Bottom	Natural	SST Nut/Washer	0.040” (1.00 mm)	2.9 µL
P-430	PEEK Elbow for 1/16” OD Tubing	1/4-28 Flat-Bottom	Natural	P-235 (2), P-200 (2)	0.020” (0.50 mm)	1.4 µL
P-432	PEEK Elbow for 1/8” OD Tubing	1/4-28 Flat-Bottom	Natural	P-335 (2), P-300 (2)	0.062” (1.60 mm)	13.6 µL
P-134	PEEK True ZDV Union	5/16-24 Flat-Bottom	Natural	–	–	–

Prod. No.

Description

Threads

Color

Includes

Thru-hole

Swept Volume

P-440

PEEK Bulkhead Union

10-32 Coned

Natural

SST Nut/Washer
